User’s GuideWelcome to EL-Link SoftwareThe Main Program Features• The EL-Link program allows sending data to a PC, and sending them back to SHARP®, s

Frequent problems:1. There is no free COM serial port connector available on the PC• The PC must have one free serial port for connecting the cable: C

3. An error message is issued in PC or SHARP after starting data communication◊ Though the PC finds the cable (the words „EL-Link” or „SHARP” are disp

• Data exchange with other programs, by keeping the accentuated characters of the code tables CWI, 852and Windows ANSI. (Excel®, Word®, Outlook®, Outl

Packing list• Data communication cable: special EL-Link cable with electronic circuit is integrated in the connector(Each items are packed after con

3. Communication SHARP=>PC Receive• The SHARP contents can be copied in an empty database by using menu commands File  New dossier(Alt-F, N). Give

• Go to the window Backup save by the menu point Communication  Backup save (Alt-C, B), specify thefile name for saving all the data stored in the SH

• Starting EL-Link the program opens the database that has been used for the last time.• If you would like to use another database you can select it i

• Other registers can be chosen by using the register tabs (Tel/Mail 1..2, URL, Memo, …etc. ), or left, right(⇓ ◊) keys.• The required data item can b

• Character deletion: at the cursor position: Delete, deleting character before the cursor position:⇓BackSpace.• New line or line feed can be requeste

• Create one shortcut icon with different working (beginning) folder to each users. The working(beginning) folder can be given in Property window (cli
