2-50 Color Calibration

Sharp AR-C360P EFI Color Guide - 50

The following illustration shows the different parts of the ES-1000.

Calibrating the Fiery with the ES-1000

You can use ColorWise Pro Tools in conjunction with the ES-1000

to calibrate the Fiery.

To calibrate the Fiery using the ES-1000

1. Start Calibrator.

For instructions on starting Calibrator, see page 2-44.

2. Choose EFI Spectrometer ES-1000 as the measurement method.

3. In the Check Print Settings pane, choose the desired calibration

set.

Choose the appropriate calibration set for the mode and type of

media which are needed for calibration.

Note:For this calibration to take effect, the calibration set must be

associated with one or more output profiles. There is no need to

make any new associations for the default calibration set, since it

is already associated with the default output profile.

Sample aperture

Measure button

White tile

reference

Calibration cradle
