8-5
TROUBLESHOOTING
Contents
(10) Paper misfeed in the finisher
Open the front cover.
While pressing the lever over
to the left, slide the finisher to
the left until it stops.
Turn roller rotating knob in
the direction of the arrow to
remove the misfed paper.
Make sure that there is no
misfed paper in the machine.
(11) Paper misfeed in the saddle stitch
finisher (top)
Open the top cover and
remove the misfed paper.
When a punch module is installed.
Open the front cover.
Turn the roller knob as
shown in the illustration.
Open the top cover and
remove the misfed paper.
