PART NAMES AND FUNCTIONS

(9) Punch module*

This is used to punch holes in output.

Requires a finisher (large stacker).

(10) USB connector (A type)

Supports USB 2.0 (Hi-Speed).

This is used to connect a USB device such as USB

memory to the machine.

For the USB cable, use a shielded cable.

(11) Saddle stitch finisher

This can be used to staple output. The saddle stitch

function for folding and stapling output and the fold function

for folding output in half are also available. A punch module

can also be installed to punch holes in output.

(12) Finisher

(large stacker)*

This can be used to staple output.

(13) Tray 1

This holds paper.

(14) Tray 2

This holds paper.

(15) Tray 3 (when a stand/1 x 500 sheet paper drawer or a

stand/2 x 500 sheet paper drawer is installed)*

This holds paper.

(16) Tray 4 (when a stand/2 x 500 sheet paper drawer is

installed)*

This holds paper.

(17) Tray 5 (when a large capacity tray is installed)*

This holds paper.

* Peripheral device.

(12)

(10)(9)

(11) (14)(13) (17)(15) (16)

When a saddle stitch finisher is

installed
