Cover Sheet
61
2. Send/Receive
Documents
Cover Sheet
You can have the machine generate a cover sheet and send it as the last page of
your fax transmission. The cover sheet includes the date and time, the receiver’s
name and number if a Rapid Key or Speed Dial number is used, the sender’s
name and number, and the total number of pages.
♦ Your name and number must be programmed in order for them to appear
on the cover sheet (see page 25).
♦ To have the recipient’s name appear, you must dial using a Rapid Key or
Speed Dial number with the name programmed.
1
Load the document(s).
• SEND READY will appear in the
display.
• Press and/or to
set the resolution and contrast if
needed.
RESOLUTION
CONTRAST
(Example)
all.book Page 61 Thursday, May 13, 2004 8:51 AM
