CODE: 00ZAL1670/A1EDIGITAL COPIERAL-1640AL-1650MODEL AL-1670[ 1 ] INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . 1

(9) Fonta. For PCLTrueDoc Format 45 fonts1 bitmap fontFont No. Font Name0 Fixed Pitch 810 Courier Roman SWC1 DutchTM 801 SWC2 Dutch 801 Bold SWC3 Dutc

[4] LIMITATIONS OF ELECTRICAL SORT <AL-1670 only>Function Limitations, No. of documentsto be readWhen no page memory (SIMM) is additionally inst

[6] SIMULATION1. Entering the simulation modePerform the following procedure to enter the simulation mode.Clear key → Exposure mode select key → Clear

4. Contents of simulationsMain codeSub codeContents Details of operationInitial valueSet range3 11 Shifter Home PositionCheck<Used only in theAL-16

[7] TROUBLE CODE LISTThis chapter is commonly used with the AL-1600 Series.1. Trouble code listTroublecodeTrouble content RemarkE1 00 ERDH board commu

[8] INSTALLING THE PRINTERDRIVERTo use this printer with your computer, you must install the printerdriver.Install the printer driver using the suppli

6) Print a test page by clicking the [Finish] button.Note: If you check “No” and click the [Finish] button, the printerdoes not print a test page afte

9) When the test page is printed properly, click the [Yes] button.• The printer is ready for printing.3. Installing onto Windows 95/98 without Using t

4. Installing onto Windows NT 4.01) Turn the computer on and start Windows NT.2) Click the Start menu, point to “Settings”, and choose “Printers”.3) W

[9] SETTING AND ADJUSTMENTS1. Configuration setting(Basic Menu Setting Procedure)Note: The menus and items displayed may be different dependingon the

Warning!This product is a class A product.If it is operated in households, offices or similar surroundings, it can produceradio interferences at other

A. Main MenuItemPossibleSettingsDescriptionCopies 1 ∼ 999 Sets how many copies to print.Resolution600dpi ∗300dpiSets the printing resolution.Smoothing

1. Samples2. Items and contentsA. Hardware status(Machine information)a. LanguageValue: (English/French/German/Italian/Dutch/Spanish/Swedish)Example:

[11] Disassembly and assemblyA Printer BoardB E-sort PWB (only AL-1670)A. Printer boardB. E-sort PWB <Only AL-1670>M3x6M3x6M3x6M3x6M3x6M3x6M3x6M

[12] FLASH ROM VERSION UPPROCEDURE1. MCU/E-SORTA. Tool● Machine● PCOperates on Windows 95/98.● Level converter (UKOG-0002QSZZ) (with serial cable)● Le

9) Select the data for MCU to be transferred.10) Select the data for the electronic sort board to be transferred.∗ For the models other than the AL-16

COPYRIGHT © 1999 BY SHARP CORPORATIONAll rights reserved.Printed in Japan.No part of this publication may be reproduced,stored in a retrieval system,

[1] INTRODCUTIONThis machine is an upgrade model of the digital copier, AL-1610.Therefore this Service Manual describes only the different points from

[3] SPECIFICATIONS1. Copy modeA. TypeType Desk-topB. Copy speed(1) Basic speed16 sheets/minScan One Print Multi AvailableCondition: Copy speed in the

J. Void widthVoid areaLead edge 1 ∼ 4 mm, rear edge 4 mm or less,both side 4 mm or lessWhen using SPF: 6 mm or lessImage lossMax. 5/32" (4 mm) (l

2. Printer modeA. Basic specificationsItem ContentsPrint speed 16 PPMResolution600 dpi, 300 dpi (1,200 dpi equivalent bysmoothing)Toner save Available

Item PCL6 PCL5eSetcontent ofwatermarkPositionDepends on the paper size.MAX Short –5.84" ∼ 5.84" Long –8.5" ∼ 8.5"Size 6 ∼ 900Ang

(6) Paper handling specificationsa. Paper feed direction1) Paper size and image transport directionPaper Size Side set to the paper feed portA3 Short

(8) Print AreaPapersizeABCDEFGHA3 7014 9920 6730 142 100 300 6814 0B4 6070 8597 5786 142 100 300 5870 0A4 4960 7014 4676 142 100 300 4760 0B5 4298 607
