15

PART NAMES AND FUNCTIONS

SIDE AND BACK

(1) USB connector (A type)

Supports USB 2.0 (Hi-Speed).

This is used to connect a USB device such as

USB memory to the machine.

(2) LAN connector

Connect the LAN cable to this connector when the

machine is used on a network.

For the LAN cable, use a shielded type cable.

(3) USB connector (B type)

Supports USB 2.0 (Hi-Speed).

A computer can be connected to this connector to

use the machine as a printer.

For the USB cable, use a shielded cable.

(4) Service-only connector

(5) Power plug

(1)

(2)

(3)

(4)

(5)
