Maintenance

132

3 Close the auto document feeder cover, pressing down on both sides to

make sure it clicks into place.

Cleaning the document glass

Open the document glass cover and clean the document glass by wiping it

with a soft, dry cloth (be sure not to use a cloth that will scratch the glass). If

needed, moisten the cloth with isopropyl alcohol or denatured alcohol.

Press down

on the marks
