20
PROGRAMS FOR NETWORK
SCANNER MODE
This chapter explains key operator programs that are used for the network scanner function. These programs can
only be configured on models that have the network scanner function.
SCANNER SETTINGS
The "SCANNER SETTINGS" consist of the following
programs:
● INITIAL FILE FORMAT SETTING
● INITIAL QUALITY SETTING
● INITIAL RESOLUTION SETTING
● DEFAULT DISPLAY SETTINGS
● THE NUMBER OF DIRECT ADDRESS / SENDER
KEYS DISPLAYED SETTING
INITIAL FILE FORMAT SETTING
Use this program to change the default file format (file
type, compression mode, and number of pages per
file) that is used when sending an image by Scan to
E-mail, Scan to Desktop, or Scan to FTP.
The factory default settings are as follows:
• File type: TIFF
• Compression mode: G4
• Number of pages per file: All
INITIAL QUALITY SETTING
This program is used to set the default original type
and exposure level for network scanner mode.
For informatin on these settings, see the operation
manual for network scanner.
The factory default settings are as follows:
• Original image type: Text/Photo
• Exposure: Auto
INITIAL RESOLUTION SETTING
This program is used to set the default resolution for
network scanner mode.
The factory default setting is "300" (dpi).
DEFAULT DISPLAY SETTINGS
Use this program to select the initial screen that
appears when the [SCAN] key is pressed to switch to
network scanner mode, or when the [CLEAR ALL] key
( ) is pressed in scanner mode.
Three selections are available for the initial screen:
• CONDITION SETTINGS
• ADDRESS BOOK (ABC)
• ADDRESS BOOK (GROUP)
The factory default setting is "CONDITION SETTINGS".
THE NUMBER OF DIRECT ADDRESS /
SENDER KEYS DISPLAYED SETTING
This program is used to select the number of
one-touch keys that are displayed in the address book
screen and sender selection screen. Selections are
[6], [8], and [12].
The factory default setting is "8" (keys).
KEY OPERATOR PROGRAMS
SCANNER SETTINGS
INITIAL FILE FORMAT SETTING
INITIAL QUALITY SETTING
INITIAL RESOLUTION SETTING
OK
1/2
Each displayed one-touch key name can be
up to 18 characters long when the number
of displayed one-touch keys is 6 or 8. Each
name can only be 10 characters long when
the number of displayed one-touch keys is
12.
Note
