Upgrading The Computer

6 - 14 Upgrading the Optical (CD/DVD) Device

6

Removing the Optical Device Drive for Model A Computers

1. Turn off the computer, and turn it over and remove the battery and primary hard

disk bay cover (see pages 6 - 9 & 6 - 5).

2. Remove the screw at point , and use a screwdriver to carefully push out the

optical device at point .

3. Reverse the process to install the new device.

4. Replace the component bay cover (see page 6 - 7).

Figure 6 - 9

Removing the

Optical Device

(Model A)

1

2

1

2

2
