Mobile Computer MC 95xx

-NI

Type B7-A29.-…………

Operation

Technical data subject to change without notice.

Issue: Revision 1 / March 2011

Page 31 of 57

4.6.8 Installed in an MC 95xx

-NI

When the 4800 mAh battery, type B7-A2Z0-0011 is installed in the MC 95xx

-NI, the user

can view the charge level (with Status button press) and health of the battery (see Figure

4-13). The Battery Status LED is disabled when the battery is installed in the MC 95xx

NI. If the battery is unhealthy, the Charge Level indicator displays an “X” (see Figure 4-

13).

Figure 4-13: Battery in MC 95xx

-NI

Press the Status button to display the current battery charge level. It will display for five

seconds and then turn off. Table: 4-2: Charge Level Indicator list the Charge Level

Indications when the Status button is pressed.

Charge Level

Indicator

Description
