6 Specifications

Computer specifications

Metric U.S.

Dimensions

Length 25.2 cm 9.9 in

Width 37.4 cm 14.7 in

Height (front to rear) 3.4 to 3.6 cm 1.35 to 1.43 in

Weight (equipped with UMA graphics, optical drive, 1

SODIMM, hard drive, WLAN module, 3 cell battery)

2.57 kg 5.66 lbs

Input power

Operating voltage 19.0 V dc @ 4.74 A – 90 W

Operating current 4.74 A

Temperature

Operating (not writing to optical disc) 0°C to 35°C 32°F to 95°F

Operating (writing to optical disc) 5°C to 35°C 41°F to 95°F

Nonoperating -20°C to 60°C -4°F to 140°F

Relative humidity

Operating 10% to 90%

Nonoperating 5% to 95%

Maximum altitude (unpressurized)

Operating (14.7 to 10.1 psia) -15 m to 3,048 m 50 ft to 10,000 ft

Nonoperating (14.7 to 4.4 psia) -15 m to 12,192 m -50 ft to 40,000 ft

Shock

Operating 125 g, 2 ms, half-sine

Nonoperating 200 g, 2 ms, half-sine

Random vibration

Operating 0.75 g zero-to-peak, 10 Hz to 500 Hz, 0.25 oct/min sweep

rate

124 Chapter 6 Specifications
