Maintenance

126

Caution!

♦

Do not use benzene or thinner. Avoid touching the print head with

hard objects.

♦

The print head may be hot if your fax machine has just received a

large number of documents. If this is the case, allow the print head

to cool prior to cleaning.

Take the imaging film cartridge out of

the print compartment and place it on

a sheet of paper.

Wipe the print head and roller with

denatured alcohol.

Roller

Print head

all-ux340L.book Page 126 Thursday, December 23, 1999 5:37 PM
