55908022-02 TECHNICAL MANUAL CXE LOW TEMPERATURE SPLIT SYSTEMS

10/14 55908022-02 NOTE When the CXE 40 is matched with a CKC 20. The restrictor in the indoor unit must be changed to 0.033" When the CXE 50 is

11/14 55908022-02 c. Place the flare nuts over the incoming pipework and flare the pipe ends. The use of a little refrigeration oil on the flaring to

12/14 55908022-02 ADDING REFRIGERANT 1. The unit is fitted with head pressure control; before charging, isolate the outdoor unit and transfer the m

13/14 55908022-02 CXE INDOOR UNIT COMPONENT IDENTIFICATION 8915123456101112134147Capillary Entry Mains Cable Entry PointInternal Earth TerminalENLSPAR

14/14 55908022-02 CKC OUTDOOR UNIT COMPONENT IDENTIFICATION TEV LTD, ARMYTAGE ROAD, BRIGHOUSE, WEST YORKSHIRE, HD6 1QF. + 44 (0) 1484 405600 +44 (

2/14 55908022-02 GENERAL INDEX CONTENTS PAGE PART NUMBERS, UNIT COMBINATIONS, OPTIONS, DIMENSIONS & WEIGHTS 3 PERFORMANCE DATA 3 AIR FLOWS,

3/14 55908022-02 CXE OPTIONS DIMENSIONS & WEIGHTS UNIT COMBINATIONS PART NUMBERSPERFORMANCE DATA (kW) MODEL CXE 40 CXE 50 CXE 70 PART NUMBER 55

4/14 55908022-02 SOUND POWER AND SOUND PRESSURE LEVELSAIR FLOWS MODEL m³/s MODEL m³/s CXE 40 0.61 CKC 20 0.81 CXE 50 0.66 CKC 40 0.72 CXE 70 0.58

5/14 55908022-02 ELECTRICAL DATA 1 PH 230V 50Hz INPUT POWER FULL LOADS AMPS COOLING HEATING COOLING HEATING SYSTEM MAX. STARTING CURRENT MODEL INDOO

6/14 55908022-02 (Wall mounted) FRONT VIEW(Wall mounted) REAR VIEW (Ceiling Mounted) TOP VIEW (Ceiling mounted) SIDE VIEW X2Z1ZX(Wall mounted) SIDE V

7/14 55908022-02 CXE ELECTRICAL CONNECTIONS CONTENTS PARTS DESCRIPTION QTY ACTION Envelope containing operating instructions and Declaration of Conf

8/14 55908022-02 CKC INSTALLATIONWIRING DIAGRAM MOUNTING Whether floor or wall mounted, it is essential

9/14 55908022-02 CKC DIMENSIONS (Dimensions in mm.) 1. Individual pipe runs to a maximum of 20m, including 7.5m lift, are
