Connectors

Caution:

This connector is only intended for service purposes.

Any connection to this terminal may cause malfunctions

of the copy machine.

Instruction for service technician:

The cable length for the service terminal has to be less

than 3 m (10 feet).

RSPF connector

Finisher connector

USB connector

CLASS 1 LASER PRODUCT

LASER KLASSE 1

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

CLASS 1

LASER PRODUCT

LASER KLASSE 1

LASER KLASY 1
