11

Part Names

1 Automatic document feeder

2 Front cover

3 Output tray (Center tray)

4 Operation panel

5 Right tray

6 [POWER] key ( )

7 Bypass tray

8 Main power switch

9 Tray 1

10 Tray 2 (when paper feed tray is installed)*

11 Tray 3 (when paper feed tray is installed)*

12 Tray 4 (when paper feed tray is installed)*

* Peripheral device.

1 2 3

5

4

9101112

7

8

6
