6-1

CHAPTER 6

MACHINE MAINTENANCE

(FOR COPYING)

This chapter explains procedures for cleaning the machine, and

troubleshooting.

Page

USER MAINTENANCE........................................................................... 6-2

●

Cleaning the document glass and the automatic document feeder .......

6-2

TROUBLESHOOTING............................................................................ 6-3
