HOW TO USE THE NETWORK SCANNER FUNCTION

(13) [FORMAT] key (page 28)

When you send an image to one or more

recipients using Scan to E-mail or Scan to FTP,

the [FORMAT] key enables you to temporarily

override the individual file format settings (file

type / compression mode) stored for each

recipient and send the image to all of the

recipients using a single file format setting.

(14) [ORIGINAL SIZE] key (page 26

)

This is used to set the size of the original to be

transmitted.

(15) [DUPLEX SCAN] key (page 25

)

Press this key to use the duplex scan function.

(when the RSPF is installed)

(16) [SPECIAL FUNCTION] key

This key is used to select a special transmission

function, configure function settings, and access

the key operator programs.

(17) Arrow keys ( )

These are used to select items and move through

pages.

(18) [START] key ( )

This is used at the following times:

(1) When starting transmission

(2) When scanning an original

(3) When configuring and storing settings

ABC DEF

JKLGHI MNO

TUVPQRS WXYZ

@.-

COPY

EXPOSURE

PAPER ZOOM

AUTO %

OUTPUT DUPLEX

SPECIAL FUNCTION

ACC. #-C

READ-END

SCAN

FAX

COLOR MODE

PROGRAM

RESOLUTION

ADDRESS FORMAT

ORIGINAL SIZE DUPLEX SCAN

DUPLEX SCAN

ORIGINAL SIZE

ADDRESS

BROADCAST

BACK

FAX STATUS

(2) (3) (4) (5) (6) (7)

(10)

(11) (12) (13) (14) (15) (16) (17) (18)

• When the auto power shut-off function

activates, all lights except the mode key

indicators go off. For information on auto

power shut-off, see the "Operation

manual (for general information and

copier)".

• For information on the keys and indicators

which are used for the copy function and

other functions, see "OPERATION

PANEL" in the manual for each function.

Note
