SPECIAL MODES
6-4
Margin shift
The margin shift function will automatically shift the text or image on the copy paper approximately 1/2" (10 mm) in
its initial setting.
1
Touch the [MARGIN SHIFT] key on the
SPECIAL MODES screen.
The margin shift setting
screen will appear.
The margin shift icon
( ) will also appear in
the upper left of the
screen to indicate that
the function is turned on.
2
Select the shift direction.
Touch a shift direction
key to select right or left.
The selected key will be
highlighted.
3
Set the shift amount as needed and touch
the [OK] key.
Use the and the
keys to set the shift
amount. The shift
amount can be set from
0" to 1" in 1/8"
increments.
If a duplex module/2 x
500 sheet paper drawer and duplex bypass/
inverter unit are not installed, the margin shift
setting for back-side copies will not be displayed.
4
Touch the [OK] key on the SPECIAL
MODES screen.
Return to the main screen of copy mode.
● The shift direction can be selected from right or left shift as
shown in the illustration.
One-sided copying
Original
Image shifted
to the right
Margin
Two-sided copying
Original
Or
Margin
Margin Margin
Image shifted
to the left
Image shifted
to the right
Image shifted
to the left
MARGIN SHIFT
CENTERING
RIGHT LEFT
About the steps that follow
If a reversing automatic document feeder is
being used, see pages 5-2 through 5-6. If the
document glass is being used, see pages 5-7
through 5-9.
To cancel the margin shift function, touch the
[CANCEL] key on the margin shift setting screen.
SIDE 1
(0 1)
inch
(0 1)
inch
SIDE 2
OKCANCEL
OK
1/2 1/2
WhaleII_general-copy_SEC.book 4 ページ ２００４年９月１４日 火曜日 午前１１時４５分
