* Factory default settings are indicated with an asterisk (*).

Press the start ( ) key. The right-hand number in the display

will be steadily lit and the entered value will be stored.

Press the light ( ) key to return to the normal copy mode.

DISPLAYING TOTAL NUMBER OF COPIES

Use the following procedure to display the total number of copies.

Press and hold down the clear ( ) key for approximately 5 seconds.

The total number of copies will appear in two steps, each with three

digits.

Example: Total number of copies is 1,234.

SPF automatic

original discharge

time (if installed)

1 5 min., *2 30 min.,

3 60 min., 4 120 min.,

5 240 min., 6 OFF

Resolution of AUTO

& MANUAL mode

*1 300dpi, 2 600dpi

21 Reset factory 1 YES, *2 NO

Prevention of OC

copies when the

SPF is up function

*1 ON, 2 OFF

Copy effective paper

width setting function

(Bypass tray)

*1 Large (A4 width),

2 Small (B5R width)

Copy effective paper

width setting function

(Tray 1)

*1 Large (A4 width),

2 Small (B5R width)

Copy effective paper

width setting function

(Tray 2 if installed)

*1 Large (A4 width),

2 Small (B5R width)

Selection of copy

start state (Polygon

rotation on/off)

*1 ON, 2 OFF

Fusing temperature

setting when the

bypass tray is used

1 Low, *2 High

To change the setting or to set another mode, press the clear

( ) key. The unit will return to step 2.

Program

No.

Mode Parameters
