OPTIONAL

EQUIPMENT

Misfeed removal

The copier will stop when a misfeed occurs. The misfeed ( ) indicator and

the red indicator which indicates the paper feed unit will blink.

Open the side cover of the paper feed unit and remove

the misfed paper.

●

Be sure to perform this step before pulling out the paper trays. If not,

the paper may be torn as the trays are opened.

Gently lift and pull out the paper tray which was in use.

Remove any misfed paper.

Close the paper tray and the side cover.

●

Confirm that the misfeed ( ) indicator has gone out.

250-SHEET PAPER FEED UNIT (AR-DE5)/2x250-SHEET PAPER FEED UNIT (AR-DE6)

250-sheet paper feed unit (AR-DE5)

2x250-sheet paper feed unit (AR-DE6)
