MISFEED REMOVAL

When the misfeed ( ) indicator blinks or blinks in the display, the unit will

stop because of a misfeed. When the SPF misfeeds an original sheet, the unit will

stop and the SPF misfeed ( ) indicator will blink, while the misfeed ( ) indicator

will remain off. For a misfeed of originals in the SPF, see "D: Misfeed in the SPF (AL-

2041)" (p.87).

Open the multi-bypass tray,

and then open the side

cover.

Check the misfeed location. Remove the misfed paper

following the instructions for each location in the illustration

below. If the misfeed ( ) indicator blinks, proceed to "A:

Misfeed in the paper feed area" (p.84).

If the misfed paper is seen from this

side, proceed to "C: Misfeed in the

transport area" (p.86).

If paper is misfed here, proceed to

"B: Misfeed in the fusing area" (p.85).

If paper is misfed here, proceed to

"A: Misfeed in the paper feed area" (p.84).
