05/12/2 CD-ES777(U)1.fm

TINSEA095AWZZ

Preparation for Use

CD-ES777

System connections

AC INPUT

AC outlet

(AC 120 V, 60 Hz)

AC power connection (see page 12)

Right speaker

AM loop antenna

Make sure to unplug the AC power cord before any connections.

Antenna connection (see page 11)

Speaker connection (see page 11)

Left speaker

Speaker light-up wire

FM antenna
