PREPARATION

To maintain the quality of the filters, they are installed in the main unit within plastic bags.

Be sure to remove the filters from the plastic bags before using the unit.

Remove the filters

Remove the Front Panel.

Pull the bottom of the Front Panel.

Remove the Active Carbon

Filter and HEPA Filter.

E-6

Be sure to remove the power plug from the wall outlet.

FILTER INSTALLATION

Remove the Filter Support.

Pinch the two tabs and lift to remove.

Front Panel

Up side Tabs

Tabs

Active Carbon Filter

HEPA Filter

Main Unit

Active Carbon Filter

Remove the Active Carbon

Filter (black) and HEPA Filter

(blue) from the plastic bags.

HEPA Filter
