LC-80LE940XLC-60LE940XLC-52LE840XLC-46LE840XLCD COLOUR TELEVISIONOPERATION MANUALLC80LE940X_EN_book.indb 1LC80LE940X_EN_book.indb 1 7/19/2012 9:

8Preparation Attaching the stand unit – 52/46LE840X• Before performing work, spread cushioning over the surface on which you will be laying the TV.

9 Attaching the stand unit – 60LE940X• Before performing work, spread cushioning over the surface on which you will be laying the TV. This will prev

10 Attaching the stand unit – 80LE940X• Before performing work, spread cushioning over the surface on which you will be laying the TV. This will pre

11 Preparation Connecting the TVNotes on installing the TV• Avoid direct sunlight and place the TV in a well-ventilated location.• Place the TV in

12 Using the remote control unit Inserting the batteriesBefore using the TV for the first time, insert two supplied “AAA” size batteries. When the ba

13TV (front view)POWEROPCSLEEPPOWERMENUINPUTVOL + /−CH3D infrared emitter*1Remote control sensorOPC sensor*2POWERindicatorSLEEPtimerindicatorOPCindica

14TV (rear view)DIGITALAUDIOOUTPUTAUDIO IN(HDMI 2/PC)AUDIO OUTPUTINAUDIO (L/R) is sharedwith AV IN)USB 1 portOUTPUT (Headphones/ AUDIO (L/R)) terminal

15Part names and functions Remote control unitEXT MEDIATV INFOMENUGUIDESLEEP56151621112891071272813417*1814252622232019212431 < (Standby/On)To sw

16Quick guide What is the HOME?You can easily launch to enjoy Internet connection and Home network function and to perform settings for the TV from t

17 Quick guideUsing software keyboardUse the software keyboard when you need to input text.Char.SetCapsCancelDoneDeleteClearCursor Left Caps Char.Set

LC80LE940X_EN_book.indb 2LC80LE940X_EN_book.indb 2 7/19/2012 9:36:40 AM7/19/2012 9:36:40 AM

18 Initial auto installationWhen the TV is powered on for the first time after purchase, the initial auto installation wizard appears. Follow the menu

19Daily operation Turning on/off the power – using the control panel of the TV Turning on/off the power 1 Turn on the power.Press < on the TV (afte

20 Watching TV (DTV only)Press > to change “DTV” or “ATV”.NOTE• When watching Digital Radio or Data broadcasting, the image is switched to DTV.•

21 Switching the digital audio format (DTV only)If multi sound modes are received, each time you press MPX the mode switches as follows.Audio (ENG)STE

22 TeletextWhat is teletext?Teletext broadcasts pages of information and entertainment to specially equipped TV. Your TV receives teletext signals br

23View settingInitial teletext page (DTV only)If you set the language of the initial page (this page is displayed for the first time after pressing m)

24 Watching TV EPG (DTV only)EPG is a programme list that is displayed on the screen. With the EPG, you can check the schedule of DTV/RADIO/DATA, vie

25 Selecting a programme using EPG (DTV only)Basic operation EDisplay the EPG screenPress GUIDE.GUIDEEPG 00120 21 22 23 0 1: Select : Enter : Back

26 4 Search a programme in a category 1 Press G. 2 Press a/b to select the desired genre, and then press ?. 3 Press a/b to select a programme you want

27 Watching TV Timer setup using EPGYou can switch to a programme at a set time. 1 Press GUIDE. 2 Press a/b/c/d to select the programme you want to s

1OPERATION MANUALENGLISHDear SHARP customerThank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of trouble-

28 E Before connecting ...• Be sure to turn off the TV and any devices before making any connections.• Firmly connect a cable to a terminal or term

29 Connecting external devicesVideo connections HDMI connectionExample of connectable devices EDVD player/recorder EBlu-ray player/recorder EGame con

30 Connecting external devicesYPB(CB)PR(CR) Component connectionExample of connectable devices EVCR EDVD player/recorderYou will enjoy accurate colou

31 Audio connections Speaker/amplifier connectionConnect an amplifier with external speakers as shown below. EConnecting an amplifier with digital/an

32 AQUOS LINK Controlling HDMI devices using AQUOS LINK EWhat is AQUOS LINK?Using the HDMI CEC protocol, with AQUOS LINK you can interactively operat

33AQUOS LINK connectionFirst connect the AQUOS AUDIO speaker system or an AQUOS BD player/AQUOS recorder that supports the HDMI CEC protocol.NOTE• Re

34AQUOS LINK Operating an AQUOS LINK deviceAQUOS LINK allows you to operate the HDMI-connected device with a single remote control unit.EXT MEDIAUse t

35 AQUOS LINK AQUOS LINK control Set to “On” to enable HDMI CEC functions.Auto power onIf this is activated, the one touch play function is enabled.

36MENUMENU EAuto power onWhen an MHL-compatible device is connected to the TV, the TV turns on automatically.• This function operates when “AQUOS LIN

37 Picture settingsGo to “HOME” > “TV Menu” > “Setup” > “Picture”.SetupAV modePictureOPC[Off][STANDARD][STANDARD]CH list:Back:EnterMenuBackl

2Connecting a PC ... 68Connecting a PC ...68Display

38Picture AdvancedThis TV provides various advanced functions for optimising the picture quality.Go to “HOME” > “TV Menu” > “Setup” > “Pictur

39 Range of OPCThe brightness level range of the OPC sensor’s automatic adjustments can be set according to your preferences. The adjustment range of

40Audio SurroundThis function produces a surround effect from the speakers.Item3D StadiumReproducing lifelike experience of excitements such that liv

41Power save settingsGo to “HOME” > “TV Menu” > “Setup” > “ECO”.SetupNo signal offECO picture controlECOEnergy saveCH listMenuNo operation of

42 Channel settingsGo to “HOME” > “TV Menu” > “Setup” > “View setting”.SetupNetwork setupAuto installationView settingChannel settingsCH list

43 Basic adjustmentButtons for “Manual adjust” operationLockPress R button.When the service is locked, you must enter your password whenever you tune

44 LabelWhen a TV channel sends its network name, the “Auto installation” detects the information and assigns a name to it. However, you can change ch

45Individual setting – PasswordView setting PasswordAllows you to use a password to protect certain settings from being accidentally changed.Go to “H

46Example of time difference with GMTLocal GMT off setCanberra Sydney+10:00SingaporeKuala Lumpur+8:00BangkokJakarta+7:00New Delhi+5:30Cairo+2:00NOTE•

47Optional features settingsGo to “HOME” > “TV Menu” > “Setup” > “Option”.SetupOption for viewOption3D setupCH listMenuTerminal settingColour

3Precautions For Daily UseObserve the following itemsMaintenance of the cabinet• When cleaning the cabinet, use a soft cloth (made of cotton, floss,

48Option 4:3 modeThe “WSS” signal has 4:3 auto-switching that allows you to select between “Normal” and “Full”.Go to “HOME” > “TV Menu” > “Setu

49Option Input labelYou can label each input source with a custom description. 1 Press b to select the desired input source from the “INPUT” menu, and

50Option Headphone out settingYou can select the headphone/speaker audio output when using the headphones.Go to “HOME” > “TV Menu” > “Setup” >

51 Additional featuresOptionGame play timeThis function allows you to display the elapsed time on the screen when “AV mode” is set to “GAME”.Go to “HO

52 Connecting to the networkTo enjoy internet services, you need to connect the TV to a router with a high speed connection to the internet. You can a

53NOTE• When using the SHARP wireless LAN USB adapter (optional accessory), try to provide as much free space around the device for best performance.

54 Network function Specifications (Wireless LAN USB adapter)Product name 802.11n Dual Band WLAN adapterStandard IEEE 802.11a/b/g/nHost interface USB

55Network function Using the skype Welcome to skypeTMYou can enjoy video calls on your AQUOS. EHow to start skypeNOTE• A broadband Internet connecti

56 5 Press a/b/c/d to select a function, and then press ?.Selected item DescriptionGo back to the previous page.Go to the next page. Refresh the page

57Network functionDISCLAIMERSThis Sharp device facilitates the access to content and services provided by third parties. The content and services acce

4Introduction• Do not place vases or any other water-filled containers on this product.The water may spill onto the product causing fire or electric

58Other useful featuresUsing a USB deviceThe TV provides you some functions using a USB device. You can select which function to use after inserting a

59 Other useful featuresDisconnecting the USB deviceWhen you disconnect the USB device, be sure to the following steps. For time shiftGo to “HOME” >

60Time shift recordingYou can record the programme you are watching to the registered USB storage device.Starting time shift recording Press REC E.•

61Time shift playbackPlayback recorded scenes of the programme being recorded.Press d during time shift recording.• The last recorded programme can b

62 Other useful featuresView setting Device registrationYou need to perform this function to register the USB storage device for the time shift.Go to

63 USB media/Home networkUSB media/Home networkIn both modes, you can enjoy viewing photos, listening to music and watching videos from external USB

64 Photo modeViewing thumbnails* This screen image is for the USB media mode. It may be slightly different in the Home network mode.Buttons for thumb

65Slide show ESelecting the BGMSetup the slide show BGM from “Select slide show BGM” by pressing B when selecting photo thumbnails. This function is a

66Video mode16 Files 8 Files 15 Files 15 Files 10 FilesButtons for file selecting operations(When using USB media mode)Buttons Description?When select

67 Other useful features Selecting the picture size for video modeYou can select the picture size in “Video mode”. 1 Select “Video mode”.• Refer to S

5Introduction3D GlassesPrevention of accidental ingestion• Keep the accessory out of the reach of small children. Small children can accidentally swa

68 Connecting a PC HDMI connectionPC HDMI 1, 2, 3 or 4 terminalsn  HDMI-certified cablePC HDMI 2 terminal*op  DVI/HDMI cable  3.5 mm stereo minij

69Adjusting the PC image automaticallyOption Auto sync.This function enables the screen to be automatically adjusted to its best possible condition wh

70PC control of the TV• When a programme is set, the TV can be controlled from the PC using the RS-232C or IP. The input signal (PC/video) can be sel

71Command listCONTROL ITEM COMMAND PARAMETER CONTROL CONTENTSPOWER SETTINGP O W R 0 _ _ _ POWER OFF (STANDBY)INPUT SELECTION AITGD____INPUT SWITCHING

72You can use special 3D glasses to watch 3D-supported images on this TV.• You can enjoy 3D movies on this TV by viewing the movie through 3D glasses

73Viewing 3D imagesMENUMENUNOTE• The TV screen may temporarily become black when the TV is trying to detect a 3D image signal and when switching from

74 Enjoying 3D image viewingWatching 2D images in 3DYou can convert normal 2D images into 3D images. 1 Press 3D. 2 Press c/d to select “2D s 3D”, and

75 3D setup EBasic operationGo to “HOME” > “TV Menu” > “Setup” > “Option” > “3D setup” > select the menu you want to set. 3D auto chan

76 Troubleshooting – 3D ImagesProblem Possible solution• 3D images are not displayed. • Is “3D auto change” set to “Off”? Press 3D to switch to 3D

77TroubleshootingProblem Possible solution• No power. • Is the AC cord disconnected?• Check if you pressed < on the TV.• When the power switch

6Supplied accessories IntroductionRemote control unit ( x 1) “AAA” size battery ( x 2) AV cable ( x 2) Component cable ( x 1)Yellow GreenPages 12 and

78ResetIf complex adjustments are made so that the settings cannot be restored to normal, you can reset the settings to the factory preset values. 1 G

79Getting informationInformationMessage list (DTV only)When new software is detected, you can confirm the update information and download the software

80AppendixInformation on the software licence for this productSoftware licenceYou can read the software licences in this menu.Go to “HOME” > “TV Me

81Trademarks TruSurround HD, SRS and the symbol are trademarks of SRS Labs, Inc.TruSurround HD technology is incorporated under license from SRS Labs,

82 SpecificationsItemLC-80LE940X LC-60LE940X LC-52LE840X LC-46LE840XResolution 1,920 x 1,080Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60T

83AppendixRemoving the standFor wall mounting with the optional bracket (AN-52AG4 or AN-80AG1) remove the stand.Before setting TV on the wall• Remove

84AppendixMounting the TV on a wallTo use this TV mounted on a wall, remove the AC cord holder and the screws at the 4 locations on the rear of the TV

85LC-80LE940XThe wall mount kit (sold separately) allows you to mount the TV on the wall.For detailed information on installing the wall mount, see th

86Dimensional drawingsLC-80LE940X421336400200998863 736996.30*11771.20*1 186711481114 609600*2*3*4179445484LC-60LE940X23*239*355*41329.12*1747.63*1386

87Dimensional drawingsLC-52LE840X648.00*157*434*327*21152.00*1299340300112382101 31420°AN-52AG4507LC-46LE840X57266345101 29420°572.67*127*21018.08*129

7 Protection against overturningThere is a danger of the product overturning in the case of a disaster or sudden collision. Carry out the following ti

88 CLEARING THE PASSWORD 1 Go to “HOME” >“TV Menu” > “Setup” > “View setting” > “Individual setting” > “Password”. 2 The password inp

FOR LOCATION ENQUIRIES WITHINNEW ZEALANDREGARDING YOUR LOCALSHARP CORPORATION OF NEW ZEALAND LIMITEDVISIT OUR WEBSITE ATSHARP CUSTOMER SERVICESTELEPHO

Printed in MalaysiaTINS-F547WJZZ12P07-MA-NPLC80LE940X_EN_book.indb 90LC80LE940X_EN_book.indb 90 7/30/2012 3:56:53 PM7/30/2012 3:56:53 PM
